Ticon 1.5″ Titanium 45deg Elbow – 1.1D Radius – 1mm/.039″ Wall (101-03823-3110)

1.50″ DIA 45 Degree 1.1D/1.65″ CLR 1mm/.039″ Wall Titanium Elbow by Ticon Industries

The 1.5″ Ticon Industries Titanium 45 elbow has a 1mm(.039″) wall thickness to work well with our 1.5? 1mm tubing.

Extruded from our 1mm thin wall commercially pure Grade 1 Titanium you wont find a lighter and higher quality bend on the market.

Each elbow is individually extruded, the ends are trimmed and then they are ultrasonically cleaned to provide a ready to weld solution right out of the package.

Features

• Material: CP1 Titanium
• Tube Diameter: 1.5 Inch
• Wall Thickness: 1mm /.039″
• Bend Degree: 45
• Bend Radius: 1.1D / 1.65″

Benefits

• Provide a perfect wrinkle free bend every time.
• Our Titanium elbows will drastically reduce the fabrication time needed for producing a full Titanium exhaust system.

Applications

• Universal

What’s In The Box?

• 1 – Titanium Elbows

Warranty

• Manufacturer Standard Warranty.
